Running two diesel generators in parallel is not as simple as connecting their output cables together. Done correctly, parallel operation gives you more power, better redundancy, and more efficient fuel use. Done incorrectly, it destroys both generators within seconds.
This is a topic that matters to a specific type of buyer: data centers scaling power capacity incrementally, mining and industrial sites with large and variable loads, hospitals requiring N+1 redundancy, telecom operators managing remote power infrastructure, and distributors who need to specify complete power solutions for major projects.
This guide explains what parallel operation requires, the technical conditions that must be satisfied before generators can be connected, the control systems involved, and when paralleling is the right answer — and when it is not.
Reason 1 — Scale power output beyond a single unit: If your facility requires 800kW of backup power but the largest practical generator for your site is 400kW, two 400kW units in parallel deliver the required capacity. This is common in data centers, large industrial facilities, and infrastructure projects where site access, weight limits, or fuel logistics make very large single units impractical.
Reason 2 — Build in N+1 redundancy: A facility with a single 600kW generator has zero redundancy — if that generator fails, the facility loses power. Two 400kW generators in parallel, each capable of carrying the full 600kW load, provide N+1 redundancy: if one unit fails, the other continues to supply the facility. This configuration is standard in hospitals, data centers, and telecommunications infrastructure where unplanned downtime has severe operational or safety consequences.
Reason 3 — Improve fuel efficiency under variable load: Diesel generators are most fuel-efficient when running between 70% and 80% of their rated load. A single 500kW generator supplying a facility that draws only 200kW at night is running at 40% load — inefficient and harmful to the engine over time (wet stacking). Two 250kW generators allow one unit to be shut down during low-load periods, keeping the running unit at an efficient load level. This is called load-dependent switching and can reduce fuel consumption by 15–25% in facilities with highly variable load profiles.
Important context: parallel operation adds significant complexity and cost to a power system. It is the right solution for facilities that genuinely need redundancy or scalable capacity. For most commercial and industrial backup applications, a correctly-sized single generator is simpler, cheaper, and equally effective.
Before two generators — or a generator and the utility grid — can be connected in parallel, four electrical parameters must match within tight tolerances. Connecting generators that are out of synchronisation causes a severe electrical fault that can damage windings, shaft couplings, and switchgear in milliseconds.
Condition | What It Means | Acceptable Tolerance | Risk if Violated |
Voltage magnitude | Both generators must produce the same output voltage | ±2% of nominal | Circulating currents damage alternator windings |
Frequency | Both generators must run at the same frequency (Hz) | ±0.2 Hz | Out-of-phase connection causes mechanical shock |
Phase angle | Voltage waveforms must be in phase at moment of connection | Within ±10 electrical degrees | High impulse current can destroy switchgear |
Phase sequence | Both units must have identical A-B-C phase rotation | Must be identical — no tolerance | Motor loads run in reverse; transformer damage |
Phase sequence is checked once during commissioning and does not change unless wiring is altered. The other three conditions — voltage, frequency, and phase angle — must be actively matched every time two generators are brought into parallel. This matching process is called synchronisation.
Synchronisation can be performed manually by a trained operator or automatically by a synchronisation controller. The right choice depends on the skill level of your operating personnel, the frequency of paralleling operations, and the consequences of a synchronisation error.
Manual Synchronisation
Manual synchronisation uses a synchroscope — an instrument that displays the phase angle difference between two generators as a rotating pointer — combined with voltmeters and frequency meters. The operator adjusts the engine governor (speed, and therefore frequency) of the incoming generator until the synchroscope pointer rotates slowly clockwise and the voltages match. When the pointer approaches the 12 o'clock position, the operator closes the bus tie breaker, connecting the two generators in parallel.
Manual synchronisation requires a trained operator, takes 2–5 minutes per synchronisation event, and carries human error risk. It is appropriate for facilities where paralleling is infrequent, operating staff are technically trained, and a synchronisation error — while costly — would not endanger life.
Automatic Synchronisation
An automatic synchronisation controller (also called an auto-sync or paralleling controller) monitors all four synchronisation conditions simultaneously and controls the engine governor of the incoming generator automatically. When all four conditions are within tolerance, the controller closes the bus tie breaker without operator intervention.
Automatic synchronisation is faster (typically 30–90 seconds), eliminates human error, and enables features such as automatic load-dependent switching, remote monitoring, and fault logging. It is the correct specification for all commercial and industrial parallel installations where generators are paralleled regularly or where operating staff are not expected to perform manual synchronisation.
Factor | Manual Synchronisation | Automatic Synchronisation |
Operator skill required | High — trained electrician essential | Low — controller handles synchronisation |
Time to synchronise | 2–5 minutes | 30–90 seconds |
Human error risk | Present — incorrect closure is possible | Eliminated — controller enforces conditions |
Load-dependent switching | Manual — operator decides when to switch | Automatic — based on load threshold settings |
Remote monitoring | Not typically available | Standard on most paralleling controllers |
Cost premium | Lower — panel with instruments only | Higher — synchronising controller required |
Appropriate for | Infrequent, supervised operations | Regular parallel operation, critical facilities |
Once two generators are running in parallel, the total load must be shared between them. Without active load sharing control, one generator will tend to take on more load than the other — potentially overloading one unit while the other runs light. This is caused by small differences in governor speed settings between the two engines.
Active load sharing: Modern paralleling controllers actively manage load sharing by continuously monitoring the kW output of each generator and adjusting engine governor signals to maintain equal load distribution. On a system with two identical 400kW generators sharing an 500kW load, active load sharing ensures each unit carries approximately 250kW — within ±5% of equal share.
Reactive load sharing: Active power (kW) sharing is managed by the engine governor. Reactive power (kVAR) sharing — the portion of electrical load that does not do useful work but still stresses the alternator — is managed by the AVR (Automatic Voltage Regulator). Both active and reactive load sharing must be correctly configured to prevent one alternator from absorbing the reactive load of the other, which causes overheating.
What happens when load sharing fails: A generator that takes on more than its share of load will overheat and trip on overload protection — potentially cascading the entire load onto the remaining generator, which then also trips. This is called a cascade failure and results in complete loss of power. Proper load sharing configuration and protection coordination prevents this.
Specification note: when ordering generators for parallel operation, always specify that units are supplied as a matched set from the same factory — same engine model, same alternator brand and model, same AVR type. Paralleling generators from different manufacturers or with different AVR types requires careful engineering and is best avoided unless you have specialist expertise.
This is the most common strategic question in power system design. There is no universal answer, but the following framework covers the key decision factors.
Decision Factor | Favour Single Large Unit | Favour Parallel Operation |
Redundancy requirement | No redundancy needed — backup only | N+1 required — facility cannot afford any downtime |
Load profile | Stable, predictable load at 70-80% of rating | Highly variable — wide swing between peak and minimum |
Future capacity growth | Load is fixed — no expansion planned | Capacity will increase — parallel units allow incremental scaling |
Operating complexity | Simple — single point of operation | Acceptable — trained staff or automatic controls available |
Site constraints | Space and access allow large single unit | Weight, access, or fuel logistics favour multiple smaller units |
Capital cost | Single unit typically lower total cost | Higher total cost — justified by redundancy or flexibility |
Maintenance downtime | Facility can tolerate planned outages | Facility must remain powered during generator maintenance |
Practical guidance: for most commercial backup power applications — hotels, office buildings, factories, warehouses — a single correctly-sized generator is the right answer. Parallel operation is justified when the project specification explicitly requires redundancy (N+1), when load growth makes scalability valuable, or when a single unit of the required size is not feasible for site or logistical reasons.
Parallel-capable generators require specific configuration at the factory. These parameters cannot easily be added after delivery. When placing your order, specify the following:
Engine and Governor
· Isochronous governor: essential for parallel operation — droop governors are not suitable for automatic load sharing
· Governor control interface: confirm compatibility with your chosen paralleling controller (Deepsea, ComAp, Woodward, etc.)
· Matched engine models: both units should use identical engine type and governor specification
Alternator and AVR
· Parallel-rated alternator: confirm the alternator is rated for parallel operation (not all are)
· Matched AVR type: both units must use the same AVR model for stable reactive load sharing
· Cross-current compensation: wiring between the two AVRs to enable reactive load sharing — specify at order stage
· Alternator brands suitable for parallel: Stamford, Leroy Somer, Marathon — all support parallel operation with correct AVR configuration
Control Panel and Synchronisation
· Synchronisation controller: specify brand and model (Deepsea 8610, ComAp InteliGen, etc.) or request factory recommendation
· Bus tie breaker: motorised ACB (Air Circuit Breaker) or MCCB rated for generator short-circuit current
· Mains (utility) breaker: if integrating with utility supply, specify closed transition or open transition preference
· Load sensing: kW and kVAR transducers for active and reactive load sharing control
· Protection relay: under/over voltage, under/over frequency, reverse power, loss of excitation
Communication and Monitoring
· Inter-unit communication: CAN bus or RS485 link between paralleling controllers
· Remote monitoring: Modbus TCP/IP, SNMP, or GSM module for remote status and alarm management
· Event log: controller must record synchronisation events, load transfer events, and fault history
We supply parallel-configured generator sets as a factory-engineered system — not as individual units that are later combined on site. Each parallel set is built, configured, and tested as a matched pair (or larger group) at our factory in Fu'an before shipment.
Our parallel generator packages include:
· Matched engine and alternator specification across all units in the set
· Isochronous governor configuration on all units
· Deepsea or ComAp synchronisation controllers — specified at order stage
· Cross-current compensation wiring pre-installed between AVRs
· Motorised bus tie ACB with shunt trip and motorised close
· Active and reactive load sharing verified under load at factory
· Full parallel system test report: synchronisation time, load sharing balance, fault simulation results
· Available from 2 × 50kW up to 4 × 2,000kW configurations
· CE certified; available with integrated paralleling switchboard in one enclosure
If you are specifying a parallel generator system for a project, send us your load schedule, required redundancy level, and site constraints. We will provide a complete system design — generator ratings, switchboard configuration, protection coordination — with a factory test protocol included in the quotation.
