The question comes up regularly on construction sites, at outdoor events, and in remote project camps: the light tower is running anyway to provide illumination -- can we also use the generator in the light tower to power our tools, charge batteries, run the site office, or supply other equipment? It seems efficient. The generator is running; why not use the available capacity?
The answer is not a simple yes or no. Light tower generators can supply secondary loads in specific circumstances -- but with important limitations that buyers need to understand before connecting equipment. The generator in a light tower is designed and sized primarily for one purpose: powering the light heads mounted on the mast. Its output capacity, duty rating, power quality characteristics, and electrical output configuration reflect that design purpose -- not the requirements of a general-purpose site power source.
This guide explains what light tower generators are, what they are designed to do, what their actual limitations are as a secondary power source, and when it makes sense to use them for combined lighting and power versus when a separate generator is the correct answer.
A light tower is a mobile or portable unit consisting of a telescoping or folding mast with high-output light heads (historically metal halide, increasingly LED), mounted on a trailer or skid-mounted base, with an integrated diesel generator to supply power for the lights. The generator in a light tower is typically a small diesel genset -- 5kW to 25kW depending on the tower size and number of light heads -- integrated into the tower's base structure.
⚡ Typical Light Tower Generator Specifications
Engine: small single-cylinder or twin-cylinder diesel engine, typically 5-15 HP. Common brands: Yanmar, Kubota, Perkins 400 series, Hatz.
Output: 5kW to 20kW depending on tower size. Most light towers use 6kW, 7kW, or 10kW generators to supply 4-6 LED or metal halide heads.
Duty rating: light tower generators are typically rated for continuous or prime duty -- they run all night providing illumination. This is actually a more demanding duty than standby, which is why light tower generator engines tend to be robust relative to their output size.
Output voltage: 120/240V single-phase in North American configurations; 230V single-phase or 400V three-phase in European and most other configurations. Not all light towers provide three-phase output -- check before assuming.
Electrical output sockets: most light towers provide standard sockets (IEC, CEE 16A or 32A, or country-specific domestic sockets) for auxiliary power. The socket capacity is limited by the remaining generator capacity after the lights are supplied.
The primary load on a light tower generator is the light heads themselves. The remaining capacity -- what is available for secondary loads -- depends on the generator output and the power consumed by the lights.
Light Tower Size | Generator Output | Typical Light Load | Available for | Practical Secondary |
Small (2-3 heads) | 5-6 kW | 0.8-1.5 kW | 3.5-5 kW | Power tools, battery chargers, |
Standard (4 heads) | 7-10 kW | 1.2-2.0 kW | 5-8.8 kW | Multiple power tools, |
Large (6 heads) | 12-15 kW | 1.8-3.0 kW | 9-13 kW | Workshop equipment, larger tools, |
Extra large (8 heads) | 18-25 kW | 2.5-4.5 kW | 13-22 kW | Significant site power; |
Metal halide (4 heads) | 10-15 kW | 4-6 kW | 4-11 kW | Limited -- MH lights consume |
The LED advantage: modern LED light heads consume 80-90% less power than equivalent metal halide heads for the same lumen output. A 4-head LED light tower might consume 1.5kW for illumination; the same tower with metal halide heads consumes 5-6kW. This difference dramatically changes how much generator capacity is available for secondary loads. If you are evaluating a light tower as a combined lighting and power unit, LED specification is essential.
Available capacity is only one dimension of the question. Power quality -- the voltage regulation, frequency stability, and harmonic distortion of the generator's output -- determines what equipment can safely and reliably run from the available capacity.
⚠ Voltage and Frequency Regulation of Light Tower Generators
Light tower generators are designed and specified for the light heads they power. LED drivers and metal halide ballasts are relatively tolerant of voltage variation -- they operate acceptably across a wide input voltage range (typically ±15-20%). This means light tower generators are often specified with basic governors and AVRs that achieve voltage regulation of ±3-5% and frequency regulation that would not meet ISO 8528 G2 requirements for commercial generator applications.
For the lights: this is entirely adequate. For sensitive loads connected as secondary equipment, it may not be. Computers, control systems, variable speed drives, and electronic test equipment may malfunction or sustain damage from sustained voltage variation outside ±5% or frequency instability.
⚠ Harmonic Distortion from Small Single-Cylinder Engines
Small single-cylinder diesel engines -- common in 5-10kW light tower generators -- produce more mechanical vibration and torque variation per revolution than multi-cylinder engines. This torque variation causes slight cyclic variation in generator output, which manifests as waveform distortion (harmonic content) in the electrical output. Total Harmonic Distortion (THD) values of 8-15% are common from small single-cylinder generator sets. For comparison, a commercial quality 4-6 cylinder generator achieves 2-5% THD.
High THD is not a problem for resistive loads (heaters, incandescent lights) or basic power tools. It can cause problems for switch-mode power supplies in computers and chargers, UPS systems, variable frequency drives, and sensitive instrumentation.
⚠ Single-Phase Output: The Three-Phase Limitation
Most light towers provide single-phase output only. Three-phase power tools, three-phase compressors, and three-phase motors cannot run from a single-phase supply. If your secondary load requirements include any three-phase equipment, verify that the light tower provides three-phase output before assuming it can supply those loads.
Despite their limitations, light tower generators are genuinely suitable for a range of secondary loads on construction sites, event venues, and remote project camps -- provided the available capacity is not exceeded and the load type is compatible.
✔ Loads that work reliably from light tower generators
Power tools with universal motors (drills, grinders, circular saws, jigsaws) -- these motors are tolerant of voltage variation and do not require regulated power supply. Resistive loads: electric kettles, space heaters, site welfare unit cooking equipment. Battery chargers for cordless tools -- most modern chargers have wide input voltage tolerance (100-240V AC) and accept the power quality of light tower generators. LED lighting for office and welfare units. Small air compressors (single-phase, below available capacity after lights). Site welfare units with basic appliances. Communications equipment (radio chargers, basic internet routers with suitable input tolerance).
⚠ Loads that should NOT be connected to light tower generators
Computers and laptops without UPS intermediation -- voltage variation and harmonic distortion can cause data corruption, supply failures, and premature component degradation. Variable frequency drives (VFDs) for motor speed control -- VFDs are sensitive to input power quality; high THD causes VFD overheating and malfunction. Medical equipment -- never appropriate for unregulated generator power without UPS and line conditioning. Sensitive measurement and test instrumentation -- power quality variation causes measurement errors. MIG welding machines with sophisticated wire-feed electronics -- these require stable power. Any load that specifies ±3% or tighter input voltage tolerance.
The most common problem when using a light tower generator as a secondary power source is inadvertent overloading -- connecting more secondary load than the available capacity after the lights, or connecting loads with high starting surges that temporarily exceed the generator's rated output.
Starting surge risk: A 2.2kW single-phase compressor draws approximately 10-12 amps running current but may draw 50-60 amps for the first 2-3 seconds at start. On a 7kW light tower generator with 5kW already consumed by lights, the available headroom is 2kW -- nowhere near enough to handle the starting surge. The generator will either trip its circuit breaker, shut down on overload protection, or allow the surge to cause a severe voltage dip that resets any electronics connected to the same circuit.
Identifying the available capacity: Before connecting any secondary load, check the generator's rated output (on the generator specification label inside the light tower base) and measure or estimate the current light load. The available capacity is the difference. Always allow a minimum 20% headroom above the total load -- never operate a generator at more than 80% of rated output continuously.
Site rule for light tower secondary power: calculate available capacity = generator rated output minus light head load, then multiply by 0.8. The result is the maximum secondary load you should connect. For a 10kW generator supplying 2kW of LED lights: (10 - 2) x 0.8 = 6.4kW maximum secondary load. Start equipment one at a time to avoid simultaneous starting surges.
Light tower generators typically have small fuel tanks -- 50 to 150 litres depending on tower size -- sized for 10-16 hours of lighting operation. When secondary loads are added, fuel consumption increases and runtime between refuelling falls.
Light Tower | Lights Only | Lights + 3kW | Lights + 6kW | Typical Tank | Runtime at |
7 kW generator | ~1.5 L/hr | ~2.2 L/hr | ~3.0 L/hr | 70-100 L | 23-67 hrs |
10 kW generator | ~1.8 L/hr | ~2.6 L/hr | ~3.5 L/hr | 100-140 L | 29-78 hrs |
15 kW generator | ~2.2 L/hr | ~3.2 L/hr | ~4.5 L/hr | 150-200 L | 33-91 hrs |
20 kW generator | ~2.8 L/hr | ~4.0 L/hr | ~5.8 L/hr | 180-250 L | 31-89 hrs |
Fuel management for combined use: When using a light tower generator for both lighting and secondary power, calculate the expected daily fuel consumption at the combined load level and plan refuelling accordingly. Do not allow the tank to run dry -- fuel starvation in a light tower generator may require re-priming the fuel system before the unit can be restarted, which takes time and skill that may not be available on a night-time construction site.
Scenario 1: Night-time construction site -- tools running alongside lights
Verdict: Yes -- with capacity check -- LED light towers with available capacity of 5kW+ can reliably supply power tools and battery chargers. Verify available capacity, connect one tool at a time, never exceed 80% of available capacity.
Scenario 2: Outdoor event -- DJ equipment, sound system, laptop, mixing desk
Verdict: No -- use a dedicated quality generator -- DJ and sound equipment requires stable voltage and low THD. Light tower generators typically cannot provide the power quality required. A dedicated generator with electronic governor and quality AVR is the correct solution.
Scenario 3: Remote road maintenance camp -- welfare unit (kettle, microwave, lights)
Verdict: Yes -- suitable for basic welfare loads -- Resistive welfare loads (cooking, heating, basic lighting) are tolerant of power quality variation. Verify available capacity after lights and do not exceed the 80% load rule.
Scenario 4: Site office with computers and WiFi router
Verdict: Only with UPS intermediation -- A UPS between the light tower generator and the office equipment isolates the sensitive loads from generator power quality. Without a UPS, computer and router failures are likely from voltage variation and harmonic content.
Scenario 5: Film or broadcast production location -- cameras, lights, monitors
Verdict: No -- dedicated clean power generator required -- Film and broadcast equipment requires generator-grade power quality (ISO 8528 G3 or better). Light tower generators cannot meet this specification. A purpose-built silent generator with quality AVR is required.
Scenario 6: Emergency temporary power -- critical facility during a grid outage
Verdict: Not recommended unless nothing else is available -- Light tower generators are not designed as standby power sources for critical facilities. Voltage and frequency regulation, protection systems, and runtime capability are all designed for lighting, not critical power applications.
When lighting and site power are both required, three configurations are worth evaluating:
1 Light Tower + Separate Purpose-Built Generator (Recommended)
The cleanest and most reliable solution: use the light tower for what it is designed for (lighting), and supply all secondary loads from a separate purpose-built generator. The additional capital cost of a second generator is offset by: correct power quality for all loads, correct capacity for actual site power requirements, correct duty rating for the hours of operation, and independent fault tolerance (light tower fault does not affect site power).
2 Single Large Generator with Lighting Distribution
A single purpose-built generator (15-100kW depending on site requirements) supplying both the light heads (via appropriate lighting distribution panels) and all other site loads. This eliminates the light tower generator entirely -- the generator is installed on a suitable base or trailer, and light heads are mounted on separate masts or towers powered from the generator distribution. More complex to set up, but all power comes from a correctly specified, quality-controlled single source.
3 Tower-Mounted Generator with Enhanced Power Output Specification
Some light tower manufacturers offer enhanced generator specifications for customers who need reliable secondary power capability -- larger generator output, electronic governor for better frequency regulation, improved AVR for voltage regulation, and three-phase output. These premium light tower configurations are a legitimate combined solution. Key requirement: confirm the generator specification explicitly meets the power quality requirements of your secondary loads before purchasing.
Check Item | What to Verify | Accept / Reject Criteria |
Generator rated output | kW rating on generator data plate | Accept if rated output minus light load |
Voltage regulation | AVR specification -- governor type | For sensitive secondary loads: require |
Output phase configuration | Single-phase or three-phase | If three-phase loads: require three-phase |
THD (if specified) | Generator manufacturer's THD | For electronics: require THD <8%; |
Available socket capacity | Socket ratings vs available capacity | Sockets should be rated for available |
Duty rating | Continuous or prime rating | Light towers should be continuous or |
Fuel tank capacity vs runtime | Tank size and consumption at | Verify runtime meets operational requirement |
✔ When to contact Leading Power
If your project requires both site illumination and reliable site power, Leading Power supplies purpose-built portable and trailer-mounted diesel generators from 10kW to 500kW that can supply both lighting distribution panels and general site power from a single, correctly specified unit. Our generators use quality Cummins or Perkins engines with electronic governors and Stamford alternators -- providing the power quality and reliability that light tower generators typically cannot match for general site power applications. We can size a combined lighting and power solution based on your site load profile. 24-hour response.
