Generator noise is the most common cause of neighbour complaints, planning objections, and enforcement action against generator installations. It is also one of the most preventable problems in generator system design -- if the noise sources are understood, the right controls are specified, and the installation is designed correctly from the start.
The challenge is that generator noise is not one problem -- it is six problems simultaneously. Engine combustion noise, mechanical noise, cooling airflow noise, exhaust noise, alternator noise, and structure-borne vibration all contribute to the total noise level at the generator boundary. Controlling only one of these sources -- for example, fitting a better exhaust silencer -- while ignoring the others produces only a marginal improvement, because the uncontrolled sources establish the noise floor below which the treated source cannot reduce the total.
This guide explains each noise source, how it travels to the noise-sensitive receptor, and the control solution appropriate for each. It then provides the practical tools to assess compliance, specify correct noise performance at purchase, and retrofit effective noise control to existing installations.
Every diesel generator produces noise from six distinct physical mechanisms. Effective noise control requires identifying which sources dominate in a specific installation and targeting those first.
Source 1: Engine Combustion Noise (Cylinder Firing)
Typical noise level: 95-105 dB(A) at 1 metre from open engine
Transmission path to receptor: Airborne -- radiates from engine block surfaces, cylinder head, and valve cover directly into surrounding air
Primary control method: Acoustic enclosure (canopy) with mass-loaded panels and absorption lining that surrounds the engine; no direct line-of-sight path from engine surfaces to outside air
Source 2: Engine Mechanical Noise (Moving Parts)
Typical noise level: 90-100 dB(A) at 1 metre -- lower than combustion but continuous
Transmission path to receptor: Airborne (direct radiation from engine surfaces) + structure-borne (through engine mounts, base frame, and building structure to remote locations)
Primary control method: Anti-vibration mounts between engine and base frame; acoustic enclosure for airborne component; isolated base structure to prevent structure-borne transmission
Source 3: Cooling Airflow Noise (Fan and Radiator)
Typical noise level: 75-90 dB(A) at radiator face -- significant at distance due to directional radiation
Transmission path to receptor: Airborne -- radiates from radiator fan in the direction of airflow; also turbulence noise from air passing through radiator core and through canopy ventilation openings
Primary control method: Baffled ventilation openings in canopy that force air through 90-degree turns lined with acoustic absorption; fan guard; remote radiator mounting where possible
Source 4: Exhaust Noise (Combustion Gas Discharge)
Typical noise level: 105-115 dB(A) at exhaust outlet without silencer; dominant at distance if poorly silenced
Transmission path to receptor: Airborne from exhaust outlet; also structure-borne from exhaust pipe vibration transmitted to building structure at attachment points
Primary control method: Industrial, residential, or critical-grade silencer in exhaust system; flexible bellows at engine exhaust outlet to isolate pipe vibration; exhaust outlet directed away from sensitive receptors
Source 5: Alternator Noise (Electromagnetic and Cooling Fan)
Typical noise level: 75-85 dB(A) -- lower than engine but contributes to total
Transmission path to receptor: Airborne -- electromagnetic tonal noise at 100 Hz (50 Hz systems) or 120 Hz (60 Hz systems); cooling fan turbulence noise
Primary control method: Acoustic enclosure containing alternator; quality alternator design with balanced rotor reduces electromagnetic noise; alternator enclosed within canopy
Source 6: Structure-Borne Vibration (Transmitted to Building)
Typical noise level: Perceived as low-frequency rumble at remote locations; measured as vibration velocity (mm/s) rather than sound pressure
Transmission path to receptor: Through engine anti-vibration mounts into base frame; from base frame into concrete plinth or building floor slab; through building structure to walls and ceilings that radiate as sound in adjacent rooms
Primary control method: High-quality anti-vibration mounts (spring type for prime power, rubber for standby); isolated concrete plinth with expansion joints; flexible connections on all pipes and cables at generator
When multiple noise sources are present simultaneously, they do not add arithmetically -- they add logarithmically. This has an important implication for noise control strategy: reducing one dominant source by 10 dB(A) while others remain at the same level gives far less than 10 dB(A) improvement at the receptor.
Situation | Dominant Source | Other Sources | Total at Receptor | Improvement from |
Open type generator, | Exhaust: 85 dB(A) | Engine: 83 dB(A) | ~88 dB(A) | N/A -- starting point |
Add good exhaust | Engine: 83 dB(A) | Fan: 78 dB(A) | ~85 dB(A) | -3 dB(A) -- disappointing |
Add silencer + | Canopy ventilation | All others attenuated | ~70 dB(A) | -18 dB(A) -- major |
Super silent canopy | All sources balanced | All sources within | ~65-68 dB(A) | -20-23 dB(A) total |
The key insight: the first 15-18 dB(A) of noise reduction from an open generator is achieved by enclosing all sources equally with a quality acoustic canopy and fitting a proper exhaust silencer. The next 5-8 dB(A) requires more precise engineering of the canopy ventilation baffles and exhaust silencer grade. Each additional decibel below 60 dB(A) requires disproportionately more investment. Know your target noise level before deciding how much to invest in control.
Solution 1: Silent Canopy (Acoustic Enclosure)
Noise reduction achievable: 18-25 dB(A) reduction vs equivalent open type (from ~98 dB(A) to ~72-76 dB(A) at 1m)
Approximate cost: $2,500-8,000 premium over open type at equivalent generator size
How it works and how to specify: A steel or aluminium enclosure surrounding the engine and alternator with: mass-loaded panels (minimum 1.5mm steel or equivalent mass); mineral wool or foam composite acoustic lining on internal surfaces (minimum 50mm thickness); baffled inlet and outlet ventilation openings that force air through 90-degree turns lined with absorption material; service access panels with acoustic seal gaskets on all edges. Specify: noise level in dB(A) at 1 metre and 7 metres with a factory test certificate. A canopy specified only in general terms ("silent") without a measured dB(A) value and test certificate is not a meaningful specification.
Solution 2: Super Silent Canopy (Enhanced Acoustic Enclosure)
Noise reduction achievable: 28-33 dB(A) reduction vs equivalent open type (from ~98 dB(A) to ~65-68 dB(A) at 1m)
Approximate cost: $5,000-14,000 premium over open type
How it works and how to specify: Same as standard silent canopy with enhanced specifications: twin-wall panels with air gap and independently-mounted inner leaf; higher-density acoustic lining (75-100mm); larger baffled ventilation sections with longer acoustic lining sections; spring anti-vibration mounts between engine/alternator and canopy frame (isolating mechanical vibration from the canopy structure itself); critical-grade exhaust silencer integrated into the canopy exhaust system. The additional 6-8 dB(A) over a standard silent canopy is achieved by addressing sources that the standard canopy leaves uncontrolled: mechanical vibration exciting the canopy panels, and residual exhaust noise breaking out through canopy ventilation.
Solution 3: Exhaust Silencer Upgrade
Noise reduction achievable: Exhaust noise attenuation: 15-20 dB(A) industrial grade; 25-30 dB(A) residential grade; 35-40 dB(A) critical grade
Approximate cost: $400-600 industrial; $600-1,200 residential; $1,200-3,000 critical -- at 100kW generator size
How it works and how to specify: Three silencer grades are commercially available, defined by their insertion loss (the noise reduction they provide): Industrial silencer: 15-20 dB(A) attenuation -- adequate for remote industrial locations. Residential silencer: 25-30 dB(A) -- appropriate for urban commercial installations. Critical silencer: 35-40 dB(A) -- required for hospital, hotel, and residential-adjacent installations. The silencer is placed in the exhaust pipe run, as close to the engine as practicable for maximum effectiveness. All silencers must be preceded by a flexible stainless steel bellows coupling at the engine exhaust outlet -- this prevents vibration transmission from the engine to the rigid exhaust pipe and into the building structure.
Solution 4: Anti-Vibration Mounts (Spring or Rubber)
Noise reduction achievable: Structure-borne vibration reduction: 15-25 dB at mount frequencies; eliminates low-frequency rumble in adjacent structures
Approximate cost: $500-3,000 per generator set depending on size and mount type
How it works and how to specify: Anti-vibration mounts are fitted between the generator base frame and the building floor, plinth, or canopy frame. Spring mounts provide better low-frequency isolation than rubber mounts and are preferred for prime power applications where the engine runs continuously. Rubber mounts are adequate for standby applications with less demanding vibration isolation requirements. Mount specification: must be selected for the specific generator set weight and engine firing frequency. Over-specified mounts (too soft) can cause resonance problems; under-specified mounts (too stiff) provide inadequate isolation. Request mounting specification from the generator manufacturer for your specific model.
Solution 5: Acoustic Plant Room (for Open Type Generators)
Noise reduction achievable: 15-25 dB(A) outside the room walls -- comparable to a standard silent canopy
Approximate cost: $3,000-20,000+ depending on room size and construction quality
How it works and how to specify: An acoustic plant room surrounds the open type generator with purpose-designed walls, floor, ceiling, and ventilation system. Effective design requires: minimum 200mm concrete block or 150mm solid concrete walls (mass law: heavier walls block more noise); acoustic door with full perimeter seal and threshold sweep; baffled ventilation duct inlet and outlet -- each with 90-degree turns lined with 100mm mineral wool; flexible exhaust pipe penetration through the wall with a residential-grade silencer outside; spring anti-vibration mounts between generator and floor slab; expansion joints between generator plinth and building structure to prevent structure-borne transmission. Common mistake: providing ventilation openings that face each other or are in the same wall -- hot exhaust air re-enters the intake, and there is a direct acoustic path through the ventilation openings regardless of baffling.
Solution 6: Acoustic Screening Wall or Barrier
Noise reduction achievable: 5-15 dB(A) at the receptor for line-of-sight blocking; no benefit for flanking paths
Approximate cost: $1,500-10,000 depending on wall height, length, and material
How it works and how to specify: An acoustic screening wall between the generator and the noise-sensitive receptor blocks the direct line-of-sight sound path. Effectiveness depends on: wall height relative to generator and receptor height (must break the direct sight line); wall length (must extend well beyond the angles to the receptor on both sides -- a wall that is too short allows sound to flank around its ends); wall mass (minimum 15 kg/m2 surface mass for meaningful barrier effect -- thin sheet metal fences provide negligible attenuation). Limitation: sound diffracts over and around the barrier and reaches the receptor via reflected and diffracted paths. A screening wall cannot reduce noise below approximately 40-45 dB(A) at the receptor regardless of wall height, because diffraction and reflection establish a floor.
Solution 7: Relocation: Increasing Separation Distance
Noise reduction achievable: 6 dB(A) per doubling of distance (inverse square law in open air)
Approximate cost: Variable -- cable extension cost; may require new plinth and fuel system; can be significant
How it works and how to specify: Moving the generator further from the sensitive receptor is the most reliable noise control measure -- it costs nothing in acoustic engineering and provides predictable attenuation. Doubling the distance from 10m to 20m reduces noise by 6 dB(A). From 20m to 40m, another 6 dB(A). The limitation is the cable length between generator and the load it supplies: longer cables mean more voltage drop, which requires larger cable cross-section, which increases cost significantly. Calculate the voltage drop in the additional cable at rated current before assuming relocation is cost-effective.
Solution 8: Operational Controls: Time Restrictions
Noise reduction achievable: Eliminates night-time noise complaints entirely; no hardware cost
Approximate cost: $0 capital cost; operational restriction on generator use
How it works and how to specify: In many urban commercial installations, the generator runs only during grid outages. Daytime noise limits are higher than night-time limits in all jurisdictions. If the generator is used for standby duty only, and most grid outages occur randomly across the day, the exposure to the night-time limit is probabilistic and low. For prime power applications where the generator runs continuously, time restriction is not applicable. For event generators or temporary installations, restricting operation to permitted hours is a legitimate and cost-free compliance strategy.
If you have an existing generator installation generating noise complaints, the approach depends on whether you have an open type or canopy generator and what the installation environment looks like.
✔ Existing open type generator with noise complaints
The most cost-effective retrofit sequence: (1) Upgrade the exhaust silencer to residential or critical grade -- this addresses the largest single noise source and is the quickest retrofit. Cost: $600-3,000. Improvement: 5-15 dB(A) at receptor depending on the original silencer grade. (2) Build an acoustic enclosure around the generator (plant room) -- this is a significant construction project but provides the most comprehensive noise reduction. Alternative: replace the open type generator with a super silent canopy unit and accept the capital cost of the upgrade. (3) Add screening walls if the site does not allow a plant room -- lower effectiveness than a plant room but significantly lower cost and easier to implement. (4) Install spring anti-vibration mounts if structure-borne complaints are present (low-frequency rumble in adjacent rooms -- a different problem from airborne noise).
✔ Existing silent canopy generator with noise complaints
If a standard silent canopy generator is still generating complaints, the most likely causes are: exhaust noise breakthrough (the standard silencer is insufficient for the location -- upgrade to critical grade); ventilation noise breakthrough (canopy ventilation openings do not have adequate baffling -- add longer lined baffle sections); canopy seal degradation (door seals and panel joint seals have hardened -- replace seals); structure-borne vibration (anti-vibration mounts have deteriorated -- replace mounts). Diagnose which source is dominant before spending on upgrades: use a sound level meter to measure at the canopy exhaust outlet, canopy ventilation openings, and canopy panel surfaces separately while the generator runs. The loudest location is the dominant source.
Use this calculation before finalising a generator installation plan. It takes less than 5 minutes and prevents the most expensive error: discovering after installation that the generator violates local noise limits.
Step 1 -- Establish the generator noise level at 1 metre: From the generator datasheet or quotation, find the noise level in dB(A) at 1 metre. This should come from a factory test certificate, not from a generic claim. If only a 7-metre figure is available, add 17 dB(A) to convert to 1-metre equivalent (using inverse square law: 20 x log10(7/1) = 16.9 dB).
Step 2 -- Measure the distance to the nearest sensitive boundary: Measure the straight-line distance from the generator's planned location to the nearest residential property boundary, hotel guest room exterior wall, hospital ward window, or other noise-sensitive receptor.
Step 3 -- Calculate expected noise at boundary: Expected dB(A) at boundary = Generator noise at 1m -- 20 x log10(distance in metres). Example: 68 dB(A) at 1m, distance 20m: 68 -- 20 x log10(20) = 68 -- 20 x 1.301 = 68 -- 26 = 42 dB(A) at boundary.
Step 4 -- Compare to local limit: Find the applicable noise limit for the time of day (day or night) and zone type (residential, commercial, industrial). If calculated noise exceeds the limit, you need a quieter generator or additional noise control. If it complies with margin, proceed. If it just barely complies, consider adding 3-5 dB safety margin for calculation uncertainty.
Safety margin recommendation: acoustic calculations in real environments are accurate to approximately ±3-5 dB(A) due to ground reflections, wind effects, and building reflections. If your calculated boundary noise level is within 5 dB(A) of the permitted limit, specify a quieter canopy or add a noise control measure. Do not design to the exact limit and then discover the real world is 5 dB louder.
The noise performance of a generator set must be specified before purchase -- not assumed based on marketing descriptions.
· Measured dB(A) at stated distance: etre and 7 metres -- from a factory load bank test certificate on the specific model, not from a generic datasheet
· Test standard referenced: (measurement of airborne noise from generator sets) or equivalent national standard -- ensures the measurement was performed using a reproducible method
· Test conditions: oad level (full load is loudest -- specify measurement at rated output, not at idle), enclosure type (open or canopy), and any silencer specification included in the measurement
· Silencer grade: grade: industrial, residential, or critical -- specify which grade is included in the quoted configuration; confirm this is reflected in the measured dB(A) value
· Anti-vibration mount type: pring or rubber -- specify spring mounts for prime power applications and any installation adjacent to occupied buildings
· Canopy panel specification: nel gauge (minimum 1.5mm steel), acoustic lining type and thickness, ventilation baffle design
✔ What Leading Power provides on noise specification
Every Leading Power silent and super silent generator set is supplied with a factory noise test certificate recording: measured dB(A) at 1 metre and 7 metres; test load (100% rated output); test standard reference (ISO 8528-10); silencer grade included in test (residential standard; critical grade available as an upgrade). We provide a noise compliance calculation for any urban or noise-sensitive site: submit your site plan with the generator location and nearest sensitive receptor distance, and we return the calculated boundary noise level and confirmation of which canopy specification achieves compliance. This service is included at no charge with any quotation for a noise-sensitive installation.
