A diesel generator that will not start is not just inconvenient -- at the moment it refuses to start, there is almost certainly a power outage in progress and someone is waiting for the generator to do its job. The pressure to restart quickly is real. The instinct to try the same thing repeatedly -- pressing start again and again -- is understandable but counterproductive. Repeated failed start attempts drain the battery, overheat the starter motor, and can introduce air into the fuel system, making the eventual correct repair harder.
The right approach is systematic diagnosis. In over 95% of cases, a diesel generator that will not start has one of five root causes: battery or starting system failure, fuel system problem, control system fault or lockout, fuel solenoid failure, or a mechanical issue that prevents the engine from turning over. Each of these produces distinct symptoms that guide the diagnosis. Identifying the symptom correctly leads directly to the cause and the fix -- usually within 30 minutes for a trained operator.
This guide uses a symptom-first approach: what you observe when you try to start, and where that observation directs you. Read your symptom, follow the diagnosis, apply the fix. If you find a different symptom at each step, update your starting point and follow the new branch.
Two quick checks before any diagnosis -- these catch the most trivial causes immediately and ensure you are not about to do something dangerous.
⚡ Check 1: Read the Control Panel
Before touching anything mechanical, read the control panel display. A DSE 7320, ComAp, or any modern generator control panel will display fault codes when the generator fails to start or when it shuts down. Read and record every fault code shown. Do not clear them yet -- the fault codes tell you what the generator detected, and clearing them before you understand them loses valuable diagnostic information.
Common fault codes on failed start:
'Low battery voltage' or 'Battery fail' -- starting system problem
'Failed to start' or 'Overcrank' -- engine did not fire after multiple attempts
'Low fuel' or 'Fuel level alarm' -- fuel system problem
'Emergency stop active' -- E-stop button pressed or circuit open
'Low oil pressure pre-start' -- oil level issue (checked before every start on some controllers)
'High coolant temperature' -- cooling system issue
If you see any fault code, address that fault directly before attempting any further start.
⚡ Check 2: Verify Emergency Stop Is Not Active
Emergency stop buttons are normally-closed switches -- the circuit is complete (allowing start) when the button is not pressed, and open (preventing start) when pressed. A pressed E-stop is the simplest possible cause of a no-start. Check every E-stop button accessible -- at the generator and at any remote panels. Ensure each button is fully released (twisted and pulled out on mushroom-head types). If the E-stop circuit was wired incorrectly or has a broken wire, the panel sees an 'active E-stop' even when all buttons are released. Test this by temporarily bridging the E-stop input terminals on the control panel to confirm the fault clears.
❌ Symptom: Nothing happens when start is pressed -- complete silence
Most likely cause: Battery discharged or disconnected; battery cable fault; control panel power failure
How to check: 1. Check battery voltage with a multimeter: below 10.5V (12V system) or 21V (24V system) = discharged. 2. Check battery cable connections -- both terminal clamps tight and corrosion-free. 3. Check main battery isolator switch -- is it in the ON position? 4. Check control panel fuse or MCB -- blown fuse or tripped breaker removes panel power. 5. Check battery charger -- is it connected and showing charging output?
Fix: Discharged battery: connect jump-start pack or external charged battery; crank and confirm engine fires; replace battery within 48 hours. Loose or corroded terminal: clean to bare metal, reconnect and torque. Blown fuse: replace only after identifying why it blew. No-charge battery: replace battery; check charger output voltage (should be 13.5-14.4V for 12V system in float mode).
❌ Symptom: Clicking sound but engine does not crank
Most likely cause: Battery partially discharged (enough to activate solenoid but not to crank); main starter solenoid contact failure
How to check: 1. Measure battery voltage under load: press start and watch the voltage -- if it drops below 9.5V (12V system), battery cannot deliver cranking current. 2. Test starter solenoid: apply 12V or 24V directly to the solenoid activation terminal while someone observes the starter -- does the starter motor shaft move? If not, solenoid or starter motor has failed. 3. Check main positive cable from battery to starter motor -- a high-resistance connection causes voltage drop under cranking load.
Fix: Low battery under load: replace battery; do not attempt jump-start repeatedly -- if battery cannot deliver cranking current on a full charge, it has failed. Solenoid failure: replace solenoid (component cost $20-80; starter replacement $150-400 for most commercial generators).
❌ Symptom: Engine cranks (starter motor turns) but does not fire -- no combustion
Most likely cause: Fuel system problem (most common); fuel solenoid not opening; air in fuel system; fuel filter blocked; low fuel
How to check: 1. Check fuel level -- is the sub-base tank empty? Even if the gauge shows fuel, physically check with a dipstick on small tanks. 2. Check fuel solenoid: locate the fuel shutoff solenoid on the injection pump or fuel line. Apply 12V or 24V directly to the solenoid while cranking -- does it click open? If no click, solenoid has failed. 3. Check fuel filter bowl: is it full of fuel? If not, there is a fuel supply restriction. 4. Check for air in fuel system: open the bleed screw on the fuel filter housing and operate the hand primer pump -- does fuel flow freely or do you see bubbles? Bubbles = air in system. 5. Check fuel quality: is the fuel clear amber? Hazy, dark, or layered fuel indicates contamination.
Fix: No fuel: refuel and bleed fuel system before cranking again. Solenoid failure: replace solenoid (most common repair). Air in system: bleed at filter, injection pump, and injectors per engine OEM bleed procedure. Blocked filter: replace primary and secondary fuel filters; bleed system. Contaminated fuel: drain tank, clean, refill with fresh fuel; replace filters; bleed.
❌ Symptom: Engine cranks, fires briefly (1-3 seconds), then stops
Most likely cause: Fuel starvation after initial combustion uses trapped fuel in injectors; air lock in fuel system; low fuel pressure from worn lift pump
How to check: 1. This symptom almost always indicates an air lock in the fuel system, or a fuel restriction that cannot sustain injection. 2. Check fuel filter: replace if overdue -- a partially blocked filter passes enough fuel for brief running but cannot sustain it. 3. Operate hand primer pump vigorously (if fitted) to build fuel pressure before cranking -- then start immediately while fuel pressure is high. 4. Check fuel lift pump: mechanical lift pumps wear over time; a weak lift pump cannot maintain injection pressure at speed. Test by disconnecting the outlet and operating the lever -- does fuel pulse out strongly? 5. Check for fuel return line restriction: a blocked return line builds excess pressure and causes erratic injection.
Fix: Air lock: systematic bleed of entire fuel system per engine OEM procedure. Blocked filter: replace both primary and secondary filters; bleed. Weak lift pump: replace mechanical lift pump ($50-200 for most commercial engines). Return line restriction: clear obstruction; replace return line if kinked.
❌ Symptom: Engine turns over slowly (sluggish crank) and does not fire
Most likely cause: Battery partially discharged with insufficient cranking speed for compression ignition; cold ambient temperature; very high engine oil viscosity
How to check: 1. Cranking speed must exceed approximately 150-200 RPM for reliable compression ignition in diesel engines. Slow cranking = insufficient compression for auto-ignition. 2. Measure cranking RPM if tachometer is available, or listen -- a healthy crank is a rapid rr-rr-rr-rr; a sluggish crank is a slow rr...rr...rr. 3. Check battery: slow crank with good battery = high engine resistance (oil viscosity, cold, or mechanical problem). Slow crank with low battery voltage = battery problem. 4. Check ambient temperature: below 10 degrees C, diesel engines crank harder and need glow plugs or intake heaters to achieve ignition temperature. Are the glow plugs activating (observe wait-to-start light on panel)?
Fix: Battery problem: replace battery. Cold ambient: verify glow plugs are functioning; allow full preheat cycle before cranking; consider block heater installation. High oil viscosity in cold: check oil specification -- correct grade for ambient temperature; wrong-grade oil (too thick for the temperature) dramatically increases cranking resistance.
❌ Symptom: Engine cranks normally but DSE/control panel shows "Failed to Start" lockout
Most likely cause: Engine fired but control panel did not detect run signal (speed pickup fault); or engine genuinely did not fire and control panel correctly locked out after overcrank
How to check: 1. Read fault code carefully: "Failed to start" means the panel sent start signal but did not detect the engine reaching run speed. 2. Check magnetic pickup (MPU): the MPU detects engine speed from the flywheel ring gear. If the MPU has failed, moved out of position, or its output signal wire has broken, the panel cannot detect that the engine is running -- even if it is. 3. Test: reset the lockout, try to start while listening. Does the engine fire? If yes but panel still shows "failed to start," the MPU circuit is the problem. 4. If engine genuinely does not fire, return to fuel system diagnosis above.
Fix: MPU failure: check MPU gap (typically 0.5-1.5mm from ring gear tooth); reconnect any loose wiring; replace MPU ($30-80 for most types). Control panel reset: after fault is cleared, reset lockout via panel menu (password required on DSE). Genuine failed start: work through fuel system diagnosis.
After any fuel system disruption -- filter change, running dry, new filter installation, or suspected air lock -- the fuel system must be bled of air before the engine will start reliably. Follow this sequence for most Cummins and Perkins generator engines.
Step 1: Loosen the primary fuel filter bleed screw (if fitted)
Most modern common-rail engines do not have manual bleed screws -- the system is self-priming. For mechanical injection engines: locate the bleed screw on the primary fuel filter housing (usually a small brass screw on the top or side). Loosen 2-3 turns. Operate the hand primer pump on the fuel filter or lift pump until clear, bubble-free fuel flows from the bleed point. Tighten the bleed screw. Do not over-tighten -- it is usually only finger-tight plus a quarter turn.
Step 2: Bleed the injection pump (if mechanically injected)
Locate the bleed screw on the injection pump. Loosen and prime again until bubble-free fuel appears. Tighten. On some engines the injection pump is self-bleeding once the filter and pre-filter are bled -- consult the engine OEM manual for your specific model.
Step 3: Crack injector return lines (if required by engine OEM)
On some older mechanical injection engines, cracking the injector return pipe fittings while cranking allows trapped air to escape from the injection system. This procedure is engine-specific -- do not attempt without consulting the OEM manual. For Cummins B and C series and Perkins 1006 series, this step is usually not required if the filter bleed was complete.
Step 4: Crank with throttle -- attempt restart
After bleeding, crank the engine. For mechanical injection engines: crank for up to 15 seconds. If the engine fires but then stops, allow 30 seconds and try again -- residual air may still be present. Most engines fully self-bleed after 2-3 start attempts once the primary air lock is cleared. For common-rail electronic injection engines: the engine management system will purge residual air automatically on cranking.
After running out of fuel completely: on most mechanical injection engines, running completely dry draws air deeply into the injection system and may require bleeding at the injection pump and individual injector lines -- a more involved procedure. Prevent this by maintaining fuel level above 20% at all times and setting a low-fuel alarm well above empty.
Symptom When Start Pressed | Most Likely Cause | First Check | Time to Diagnose |
Complete silence -- no click, | Battery flat or disconnected; | Check battery voltage; | 5 minutes |
Single or rapid clicking -- | Battery too weak for cranking | Measure battery voltage while | 10 minutes |
Cranks strongly but | Fuel solenoid not opening; | Check fuel level; check fuel | 15-30 minutes |
Fires for 1-3 seconds | Air lock in fuel system; | Replace fuel filters; bleed system; | 20-45 minutes |
Slow sluggish crank, | Weak battery; cold ambient; | Measure cranking voltage; | 10-20 minutes |
Normal crank but panel | MPU (speed pickup) fault; | Listen -- is engine firing?; | 15-30 minutes |
Engine starts then shuts | Protection shutdown (low oil, | Read control panel fault code; | 5-10 minutes |
Systematic field diagnosis resolves the majority of no-start situations. However, some fault conditions require specialist tools, engine-specific knowledge, or components that should only be disturbed by trained technicians.
⚠ Stop and call a specialist for these fault conditions
Engine will not turn over manually (blocked rotation when you try to turn the crankshaft by hand): possible hydraulic lock from water in cylinders. Do NOT attempt to start. This requires specialist investigation before the engine is turned. Attempting to start with water in cylinders causes connecting rod failure.
Injection pump or common-rail system fault codes: these require engine OEM diagnostic software and calibrated test equipment to diagnose correctly. Attempting to adjust fuel delivery settings without correct tools causes further damage.
Internal engine noise (knocking, grinding) during cranking: indicates internal mechanical damage. Continuing to crank risks catastrophic failure.
Any fault that has recurred more than twice without a clear diagnosis: a recurring fault that you cannot identify requires escalation to a technician with access to full diagnostic capability.
After resolving the fault, do not immediately put the generator under full load. Follow this restart sequence to confirm the repair is complete and the generator is fit for service.
· Step 1 -- Clear faults: m the control panel; reset any lockouts
· Step 2 -- No-load run: ow to run at no load for 3-5 minutes; monitor oil pressure, coolant temperature, voltage, and frequency; confirm all parameters within normal range
· Step 3 -- Gradual loading: t 25% of rated load, confirm stable; then 50%, confirm stable; then full load; monitor exhaust colour -- should be light grey at rated load
· Step 4 -- Log the fault: e, and the corrective action in the generator service log -- this information is invaluable for identifying recurring issues and improving maintenance scheduling
· Step 5 -- Address root cause: ure: replace the battery within 24 hours, even if the generator is now running on a jump-started or borrowed battery
The most reliable generator is one that has never had a starting failure. Three preventive actions eliminate over 80% of all starting failures before they happen.
✔ Monthly Auto-Start Test
Simulate a mains failure once per month: disconnect the grid supply at the ATS, confirm the generator starts automatically and transfers load within the specified time, run for 30 minutes under load (minimum 50% of rated output to prevent wet stacking), reconnect the grid, confirm automatic retransfer. Document the test result. This single test catches battery degradation, fuel solenoid wear, MPU drift, and control panel issues before they cause a real failure at a critical moment.
✔ Battery Float Charger -- Always On
A float charger maintains the start battery at full charge at all times without overcharging. The charger costs $80-150 for a commercial-grade unit. It eliminates the most common single cause of starting failure: battery self-discharge during extended idle periods. Every standby generator should have a float charger. Every generator that has experienced a battery-related starting failure should have a float charger installed as part of the corrective action.
✔ Fuel System Maintenance on Schedule
Replace fuel filters at every 250-hour service or every 3 months -- whichever comes first. In markets with poor fuel quality (high sulphur, contamination risk), replace every 150 hours. Treat stored fuel with biocide at every delivery during the wet season. Check fuel tank water bottom monthly. These actions prevent the fuel system blockages and contamination that are the second most common cause of starting failures.
✔ Leading Power technical support for starting problems
If you have a Leading Power generator that will not start and you have worked through this guide without resolving the issue, our technical support team is available 24 hours. Send us: the control panel fault codes, what symptom you observe when you press start, the generator model and engine type, and what maintenance has been performed recently. We will diagnose remotely based on this information in most cases. For generators with DSE 8610 or ComAp InteliGen panels with Ethernet connectivity, we can access the fault log and real-time parameters remotely to assist diagnosis. Contact us at the number or email on your generator documentation.
